4 Switch Flat Touch Dash Mount

4 Switch Control Module

The Auto Rod Controls 4 Switch Flat Touch Dash Mount is a complete plug-and-play switch panel system designed for race cars, street rods, and custom builds where a clean, professional cockpit is a priority. Each kit includes the switch panel, relay board, and wiring harness, so everything needed for a full installation is in the box. The flat touch panel measures 4-7/8" L x 2-3/8" H x 3/4" D and mounts via Velcro directly to the dash with no cutting required, keeping the installation clean and reversible. LED light bars indicate switch status at a glance with red for off and green for on, and a library of 58 race and street labels lets you backlight each switch position to match your specific setup.

Beyond the four primary switch positions, this unit supports four additional fuse/relay sections controllable via grounding inputs from an ECU or EFI system, making it a natural fit for fuel injected performance builds. Any switch position can be configured as maintained on/off or momentary push action, and a master kill switch allows any, none, or all switches to be cut simultaneously for safety. The system is 16V compatible, accepts a firewall keypad for under-hood switch access, and includes cable connector retaining brackets. Backed by a lifetime warranty and available in white, black, carbon fiber white, and carbon fiber black faceplate finishes.

Switch Panel Dimensions: 4-7/8” L x 2-3/8” H x 3/4” D

FEATURES

• 11/16” Thick front to back
• 16V Compatible
• LED light bars Red off – Green on
• Library of 58 race & street labels to back light over light bars
• Duplicate words in white to place on relays
• Ability to make any switch location be on/off or push action momentary
• Master kill switch turning off any – none or all of the switches at the same time for ultimate safety
• No dash cutting, units Velcro mount to dash. For new flush mount brackets go to accessories
• No bundle of wires coming down the roll bar
• Accepts a firewall keypad which allows you to run the first 4 switches from under the hood
• Cable connector retaining brackets
• The only systems to carry a lifetime warranty
• Each unit ships with a wiring harness, label kit, and connector kit
