HD10 Series Connectors and Accessories

WELCOME TO THE DEUTSCH ASSEMBLER!

Finding all the parts for your next deutsch connector assembly has never been easier. The WireCare Deutsch Assembler was built to make the process of finding everything you need for your assembly quick and painless. Simply select the plug or receptacle and we'll sort the rest for you.

1. CHOOSE YOUR SERIES

SELECT DEUTSCH CONNECTOR SERIES

SELECT CAVITIES

2. CHOOSE YOUR CONNECTOR ASSEMBLY PARTS

SELECT WHAT YOU NEED

SELECT DESIRED CONNECTOR

Contact Diagram:Sketch image of deutsch connector pin and socket layout
SELECT RECEPTACLE
HD14-5-16P_Front

SELECT PINS
Size 16 Pins x 5
0460-202-16141
SELECT PLUG
HD16-5-16S_Front

SELECT SOCKETS
Size 16 Sockets x 5
0462-201-16141

3. CHOOSE YOUR ADD-ONS

Select any accessories from the list below to add to your deutsch assembly. All of the items shown below are compatible with the connectors you have chosen for your assembly. Be sure to double check that you order the correct quantity of these accessories. Although these items are not a required part of your assembly they may improve your results.

SELECT ACCESSORIES

HDC16-5
Receptacle Dust Caps
NO COMPATIBLE GASKETS FOR

MODIFICATIONS
Deutsch HD10-5BT-BK
Boots
Sealing Plugs
114017
Size 12, 16
0413-217-1605
Size 16

4. CHOOSE YOUR TOOLS

Select any tools from the list below to add to your deutsch assembly. All of the items shown below are compatible with the connectors you have chosen for your assembly. Although these items are not a required part of your assembly they may improve your experience.

SELECT TOOLS

0411-336-1605
Size 16 Contact Removals
CT4-8 8 indent crimper for solid contacts
Size 16 Crimpers
HDT-1561 - Single Indent Field Service Crimper for size 12/16/20 Solid Contacts
Size 12, 16, 20 Crimpers

YOUR SELECTIONS

Receptacle
HD14-5-16P
    1 piece x $12.92 each = $12.92
0460-202-16141
    5 piece x $0.58 each = $2.90
Plug
HD16-5-16S
    1 piece x $15.97 each = $15.97
0462-201-16141
    5 piece x $0.6 each = $3.00
Accessories & Tools
Your deutsch Assembly Total:
$34.79
